- Top LED Lighting Manufacturer in China
Philips 2835 SMD ,LM80 approval
Boke Flicker free driver
CRI 80 and CRI 90 are available
Low Glare with UGR<17
Light source can be 140lm/w, complete luminaire is 90-100lm/w
Sdcm<3 THD<15
5 Years warranty
| Model No | IT-DL-2.5"- 7W- M2 | IT-DL-3" -10W- M2 | IT-DL-4"-15W-M2 | IT-DL-6"-20W -M2 | IT-DL--8"-30W -M2 |
| Input Power | 7W | 10W | 15W | 20W/30W | 30W/35W |
| Product Size | D92mm*H53mm | D104mm*H55mm | D135mm*H66mm | D190mm*H90mm | D224mm*H98mm |
| Cut out size (mm) | 75mm | 95mm | 120mm | 160-170mm | 200mm |
| CCT | 3000-6000K | 3000-6000K | 3000-6000K | 3000-6000K | 3000-6000K |
| CRI | 82 /90 | 82/90 | 82/90 | 82/90 | 82/90 |
| Input Voltage | 100-240V AC | 100-240V AC | 100-240V AC | 100-240V AC | 100-240V AC |
| luminous flux (lm) | 600-700lm | 900-1000lm | 1400-1500lm | 1800-2000lm/ 2700-3000lm | 2700-3000lm/ 3200-3500lm |
| Beam Angle | 70° | 70° | 70° | 70° | 70° |
| Working Temp | -20˚-50˚ | -20˚-50˚ | -20˚-50˚ | -20˚-50˚ | -20˚-50˚ |
| Warranty | 5 Years | 5 Years | 5 Years | 5 Years | 5 Years |
| Lifespan | 50000H | 50000H | 50000H | 50000H | 50000H |
